Kaeser MOBILAIR M58 Utility Rotary Screw Air Compressor - 210 CFM, Diesel
The M58 Utility is the narrow one - 33 inches wide, 85 long, direct drive, built to live permanently on a service truck or in a utility body rather than behind a hitch. It still puts out 210 CFM, more than the towable M55PE, off a 28-gallon tank. Sandblast check valve is standard equipment on this model rather than an option.
The M58 Utility is the narrow one - 33 inches wide, 85 long, direct drive, built to live permanently on a service truck or in a utility body rather than behind a hitch. It still puts out 210 CFM, more than the towable M55PE, off a 28-gallon tank. Sandblast check valve is standard equipment on this model rather than an option.
Every MOBILAIR shares the same core engineering. The large, slow-turning SIGMA PROFILE® airend delivers 15–20% more air per gallon of fuel than comparable units, which is the single biggest line item over a machine's life. The anti-frost valve holds discharge air temperature high enough that ambient moisture will not freeze in the tool, protecting air motors and extending tool service life. Heavy-duty chassis and canopy resist corrosion; package airflow is routed to keep the engine cool under load; and the cold-start battery means the unit turns over in winter. Towable models ride on torsion bar suspension with even weight distribution.
Specifications
| Model | M58 Utility |
|---|---|
| Free air delivery | 210 CFM @ 100 psig |
| Engine | Kubota V2403-CR Tier 4 Final |
| Fuel | Diesel |
| Brake horsepower | 43 BHP @ full load |
| Full load speed | 1800 - 2600 rpm |
| Off load speed | 1800 rpm |
| Drive type | Direct |
| Fuel tank capacity | 28 gal |
| Air discharge outlets | 2 x 3/4" + 1 x 1" NPTF |
| Dimensions (L x W x H) | 85 x 33 x 55 in. |
| Shipping weight | 2,249 lb (approx.) |
| Sound level | 76 dB(A) max at 23 ft |
| Mounting | Utility / skid |
Free air delivery by pressure
| Pressure | Delivery |
|---|---|
| 100 psig | 210 CFM |
| 145 psig | 175 CFM |
Specifications from the Kaeser MOBILAIR price list effective 07-01-26 and the USMOBILAIR brochure 01/26. EX WORKS shipping point. Prices and specifications subject to change without notice.
Specifications
| Air Treatment Package | Standard - no aftercooler or Aftercooler + centrifugal separator |
| Cold Weather Package | Standard ambient or Low temperature package (min. ambient -13 °F) |
| Discharge Pressure | Standard pressure or 145 psig |
